PRECISION SHEET METAL LAYOUT MANUAL"Books are copyrighted"I am the Author of this book and have been in the Precision sheetmetal trade for over 25 years!I have my own business (over 15 years now) doing CNC programming for turret punch presses, laser, and plasma cutters, also I do 3D Sheet Metal solid or wireframe design and unfolding to flat pattern layouts using Cadkey.Any questions? Please email at david@dvcplanners.com More info at: [please contact me for website address]
This Precision Sheet Metal Layout Manual will help the beginning shop employee or student to understand how to use basic math, trigonometry and geometry in the development of flat patterns. It is designed to be used with a scientific calculator encouraging more productive and efficient layout procedures.
The manual instructs how to do flat pattern development of 90 degree, obtuse and acute bend angles. It teaches how to use bend deduction or bend allowance formulas, bend reliefs, corner notching, joggles, hems and much more.
It is written in a workbook style format that starts with basic concepts and builds up to more complicated problems. These illustrations are samples from the manual.
DVC PlannersBend Allowance, Bend Deduction Tables and CalculatorforExcel Spreadsheet (version 2000+)OK You Precision Sheet Metal Mechanics here is a tool you can use!
The license will include 1 year of free updates as I improve this.The Bend Allowance Table will calculate angles up to 360° and Material Thicknesses up to .800" and an inside bend radii up to 630.00"The Angle, Radius and Material Columns can be changed to whatever you want and the whole table is updated to relect the new values!
Spreadsheet includes illustrations of how to use Bend Deductions or Allowances.
Print out your own tables for use on the floor!
You are purchasing a license to use the software.
[please contact me for website address]
Don't be afraid to ask any questions!
.SCREEN SHOT OF THE Bend Allowance Sheet!
Paypal preferred but I will accept Cashier Checks, Money Orders or Business Checks. Product will ship via USPS Media Mail when payment is received and/or checks clear. Shipping and Delivery Confirmation included! (USA Only) Canada Pays Actual Postage. Payment must be received within 10 days of Purchase.
| | | | | | |  | |  |
|
